Name: FIREWOOD PROCESSOR: XYLOG 520
SKU: 9351
Availability: InStock

FIREWOOD PROCESSOR: XYLOG 520

$0.00

FIRE WOOD PRODUCTION, THIS PROCESSOR TAKES 20 INCH DIAMETER LOG.

VERSATILE AND COMFORTABLE MACHINE WHICH ENABLES YOU TO DEVELOP YOUR LOGS INTO FIREWOOD.

INPUT FEED CONVEYOR OPTIONS

OUTPUT CONVEYOR OPTIONS

POWER OPTIONS

SAW DUST COLLECTION

BUILD OPTIONS

GENERAL CHARACTERISTICS

Cutting diameter up to 520 mm.
Quick and easy adjustment of the cutting length from 200 mm up to 500 mm.
Wood sawing through carbid circular blade: Ø 1300 mm max.
Adujstable log section splitting from 30 to 250 mm with 2 "V" shaped blades (22 T power).
Operator-friendly cab (comfortable seat, sound proofing, air conditioning, heating or even radio).
Manual or automatic sawing.
Output conveyor hydraulically orientable (40°).
Swreening system with hedgehog rollers.
Easy lmintenance:
- remote draining
- easy access to the hydraulic and electric chambers
Machine connected via Wifi allowing a fast and efficient distance technical support.

TECHNICAL CHARACTERISTICS

Model	XYLOG 520
Power	22 T with automatic continuously variable speed ISO POWER
Cutting diameter	Max. 520 mm
Cutting system	Ø 1300 mm carbide saw blade with linear displacement through cylinders
Cutting length	From 200 to 500 mm
Splitting system	2 V-shaped blades
Deck	With chains - 2-8 m length
Output conveyor	5 or 6 m length with metal bars (adjustable in height)
Weight	Mobile version: 8.5 T
Drive	PTO 540 RPM or electric or thermal
